HD 3MP IR-cut infrared cut M12 lens Mount Double Filter for HD CCTV IP Camera Mount

Performance parameters

Product material:Plastic

Driving voltage:3.5-12V

Driving current:58-207mA

Coil impedance:60Ω ± 5% (20℃ Temp)

Driving time:<60ms

Filter thickness:0.145mm, 0.21mm, 0.3mm optional

Filter coating:Filter coating with IR film and AR film.

Switching life:500 thousand times

Adapter lens:M12 mount lens

Outline dimension:28mm*26.5mm*11.8mm

Window hole:Φ7.8mm

Fixed hole spacing:22mm

Lead out line:85mm(Optional length)

Working temperature:-20℃~80℃

Product characteristics

The positive polarity is red and black are negative, polarity reverse order is red and blue negative.

The red filter requirements in the center before product package.

High temperature resistance and no deformation.

Provide different matching schemes according to the customer's requirement.

With IR CUT Without IR CUT

With IR CUT Without IR CUT
